ZSHigh Speed nail making machine
Huarui Machinery
ZS High Speed nail making machine
High Speed Nail Making Machine Full Automatic Nail Machine
Highlight Advantages:
1.Long service life,no less than the traditional common nail making machine, for at least 10 years. White belt at low cost and long life which is 5-6 months without an incorrect operation.
2.Automatic oiling , few lubrication points, much less than traditional machines and other nail making machines on market. It is still very tidy when operating.
3.Double-mode double-punching die structure (Double molds, Double punch pin. One nail cutter, made of imported alloy, the service life is 2-3 times that of ordinary mold.
4. Reduce the cost of making nails. (the nail making speed is 800pcs / min, which effectively reduced 50% -70% nail labor work.
5. Reduce the cost of coiling nails (Effectively reduce 35%-45% coil nail labor work).
6. Greatly improve the weight of the product and reduce the production cost (Improvement of nailing and coil-nailing efficiency. Reduction of waste nails. The reduction of energy consumption, etc. at least effectively reduce the production cost of the nails by more than $20/ ton, which Improved the core competitive ability of the factory).
7. Power saving.
8. Increase the output : The capacity of high speed type is 3times compared with the common type.
Model | ZS2 High speed nail making machine | ZS3 High speed nail making machine | ZS4 High speed nail making machine | ZS5 High speed nail making machine |
Diameter of nail | 1.8-2.6mm | 2.3-3.4mm | 2.8-4.1mm | 4.1-5.2mm |
Length of nail | 25-50mm | 40-76mm | 50-100mm | 90-150mm |
Motor power | 5.5KW+2.2 | 5.5KW+2.2 | 7.5KW+2.2 | 7.5KW+2.2 |
Nail making speed | 1000-1100pcs/min | 1000pcs/min | 600-700pcs/min | 500-600pcs/min |
L*W*H | 2.0m*1.6m*1.3m | 2.0m*1.7m*1.4m | 2.15m*1.8m*1.4m | 2.2m*1.8m*1.4m |
Weight | 3000KG | 3200KG | 3300KG | 3500KG |
2.Nail polishing machine
3.Finished nails:
4.CE certification:
