Welcome to Xuchang Huarui Machinery Co.,Ltd.
 |
| Quantity: | |
|---|---|
HR28-100 , HR28-260
Huarui
Features:
The steel bar thread rolling machine is novel in design, advanced in technology, light and handy. The operation is simple, the degree of automation is high, and the rib-stripping and rolling straight thread is formed at one time. The thread profile is of good quality and high precision. The length of the thread is the same as the length of the straight thread, and there is no complete thread exposed on the connected rebar head. The steel bar thread rolling machine is a machine that uses advanced rib stripping and rolling technology to process straight threads at the connecting ends of steel bars. The steel straight threaded metal fiber processed by it is continuously dense and has good comprehensive mechanical properties. High tensile strength and high fatigue strength.
Main Technical Parameters:
model | HR28-100 | HR28-260 |
Main motor | 11KW | 22KW |
Hydraulic motor | 4KW | 15kw |
Roller diameter | 120-180mm | 230-270mm |
Dimensions | 2000*1600*1750mm | 2900*2200*2500mm |
Processing range | φ 25-90mm | φ 32-165mm |
Hydraulic pitch | 0.1-16mm | 1-25mm |
Rotating speed | 0-50r/min | 0-25r/min |
weight | 3000 KG | 9000 KG |
Applications:
More Pictures :
